Advancing High-Speed Broadband with Fixed Wireless

Service providers can use the latest technology to deliver high-speed broadband services to their customers over the last mile using multiple license spectrum, or the shared-spectrum Citizens Broadband Radio Service (CBRS) over 4G and 5G LTE technology. CBRS is a band of the radio-frequency spectrum from 3.5GHz to 3.7GHz that the FCC has designated for sharing among three tiers of uses: incumbent users, priority licensees, and generally authorized, which is unlicensed. The incumbent users include satellite ground stations and the Navy.

Compared with previous mobile network technologies, 4G LTE offers much higher bandwidth (speed of data transfer), lower latency (after response times from the network), and improved spectrum efficiency (increasing overall network capacity). This allows:

  • More applications to be used on mobile devices, out of the home or office
  • Faster or real-time sharing of large files and streaming media
  • Near-immediate delivery of time-sensitive data, such as for real-time interaction or transactions
banner-family-patio-tablet



banner-teleconferencing

LTE will deliver improvements in the performance of many existing applications, and make feasible new applications that depend on reliable high speed or responsive data transfer. Examples include innovative telemedicine applications, remote monitoring, fully-mobile virtual desktops, and high definition mobile videoconferencing. The improved user experience and practicality of LTE will also hasten the uptake of those existing applications that already work on mobile devices - but just not very well. Finally, LTE's high bandwidth can support the rapid set-up of temporary workplaces, as an alternative or backup to fixed broadband connections.

The Zyxel LTE Series indoor and outdoor CPE enables service providers to deploy wireless broadband internet connectivity in rural and remote areas where the deployment of DSL, cable, and fiber is cost-prohibitive. The Zyxel LTE Series products support both bridge and router functions to maximize flexibility in deployment and incorporate high gain antennas for better signal performance in different deployment scenarios.

LTE-solution-banner-with-8-icons-neon-blue-1

outdoor-LTE-2

Zyxel Outdoor LTE CPE

Zyxel offers a range of outdoor LTE CPE that operate on CBRS or licensed frequency bands. Zyxel outdoor CPE has built-in high-gain antennas for better performance, temperature hardened enclosure, and intuitive configuration and management tools, including a mobile app.

LTE-V2-01_FinalLTE-V2-02

Our Solutions are Made to Provide Reliable Performance in Harsh Environments

Designed to be easily deployed and integrated into existing network environments, LTE7461, LTE7480 and LTE7485 outdoor CPEs are housed in robust IP68 enclosures to protect them from damage from harmful dust and water when deployed in harsh outdoor environments.

outdoor-LTE-3

Ease of Deployment and Management

Our LTE CPE is easily installed on a wall or pole and features integrated 802.3af/at PoE PD (power device) support eliminating the need to locate the device near a power source. Zyxel LTE MobileApp for Android and iOS enables service providers to set up, manage, and monitor customer CPE from a mobile device. Our LTE Series supports TR-069, remote GUI, and remote FTP to simplify remote configuration, software upgrades, and network management, as well as the cloud-based Band Pilot LTE management system.

Band Pilot icon_green

Zyxel LTE Band Pilot is a cloud-based remote management system designed to help service providers remotely manage Zyxel LTE CPE products. Key features include remote troubleshooting, monitoring online status for all devices, RF performance history tracking, remote firmware upgrades, and TR-143 speed tests. These features allow an operator to provide a reliable network and better internet connection/experience for end-users.



Dashboard

CPE Summary on Dashboard and Intuitive User Experience

The operator can find the device information summary on the dashboard quick view including online devices, models, and the Firmware version for each. For more detailed information, simply click on the CPE group in the pie chart.



Performance History

Graphic RF Performance History

Provides a histogram on an hourly/daily/weekly/monthly basis for RF information such as RSRP, RSSI, RSRQ, and SINR. Supports one-click Zoom In and Zoom Out feature to know the detail of each period of time.



Firmware Management

Manage Firmware Upgrade Maintenance More Easily

Allows operator to run Firmware upgrade for individual or multiple devices and manage the status of all the upgrade tasks.

Remote Troubleshoot

Remotely Troubleshoot with TR143-based Speed Test, Ping, and Traceroute Diagnostic Tools

The LTE Band Pilot remote management system provides a set of tools for operators to be more efficient and responsive in helping end-users. They can troubleshoot by using TR143-based download/upload speed tests and diagnostic tools such as ping, traceroute, reboot, and/or reset functions. The use of these functions shortens operators’ response time to end-user complaints, meanwhile, reducing the expense of dispatching technicians for onsite troubleshooting.





INDOOR

OUTDOOR

LTE-group-photo



LTE5388-Front

LTE5388

CAT16 CBRS Indoor CPE

img_lte7461_475

LTE7461

Multi-licensed Band Outdoor CPE

img_lte7461_475

LTE7480

CAT16 CBRS Outdoor CPE

img_lte7461_475

LTE7485

CAT16 High-Power CBRS Outdoor CPE

LTE Band

B48 (B42/43)*

2/4/5/7/12/13/ 25/26/29/66

B48 (B42/43)*

B48 (B42/43)*

Category

CAT-16

CAT-6

CAT-16

CAT-16

Max DL/UL (PHY)

580/30 Mbps
(TDD Config. 2)

300/50 Mbps

580/30 Mbps
(TDD Config. 2)

580/30 Mbps
(TDD Config. 2)

Output power (max. TX EIRP)

23 dBm (CBRS EUD)

30 dBm

23 dBm (CBRS EUD)

36 dBm (CBSD Cat. B)

MIMO/Antenna

4x4

2x2

4x4

4x4

Operating Mode

Bridge & Router

Bridge & Router

Bridge & Router

Bridge & Router

GUI

Responsive

Responsive

Responsive

Responsive

Remote Management

TR069/TR-143
& Zyxel Band Pilot

TR069/TR-143
& Zyxel Band Pilot

TR069/TR-143
& Zyxel Band Pilot

TR069/TR-143
& Zyxel Band Pilot

Mobile App Yes

Yes

Yes

Yes

Yes

Enclosure

Indoor

IP68

IP68

IP68

Availability

August 2020

Available

Available

July 2020

*The listed connection rate is the theoretical maximum. The actual data transfer rate will vary depending on the network environment.

LTE-group-photo



Zyxel’s family of LTE products also includes the Citizens Broadband Radio Service (CBRS) Outdoor Router and LTE7461 Multiple-Licensed Band Outdoor Router which combine LTE network technology and high-gain antennas to provide lightning-fast Internet connectivity to hard-to-reach customers. Zyxel’s 5G products also include the 5G New Radio Sub 6GHz Outdoor router and Indoor router, which deliver greater performance, spectrum efficiency, and latency compared to current LTE standards.
